MITSUMI
Video Switch · 75Ω driver · Y/C mix MM1501
Absolute Maximum Ratings
(Ta=25°C)
Item Symbol Rating Unit
Storage temperature T
STG - 40~+125 °C
Operating temperature T
OPR - 30~+75 °C
Power supply voltage V
CC 15 V
Allowable loss
When alone Pd 200 mW
When mounted on board Pd 350 (
*
)mW
Recommended Operating Conditions
Item Symbol Rating Unit
Power supply voltage V
CC 4.5~13 V
Electrical Characteristics
(Except where noted otherwise, Ta=25°C, V
CC
=5V)
Item Symbol Measurement conditions Min. Typ. Max. Unit
Consumption current I
CC Refer to measurement procedures 3.7 4.8 mA
Input pin voltage V
IN No-signal, no-load 2.70 2.90 3.10 V
Output pin voltage V
OUT No-signal, no-load 2.15 V
Voltage gain G
V Refer to measurement procedures - 0.5 0 +0.5 dB
Frequency characteristic fc Refer to measurement procedures
- 10+1dB
Differential gain V
CC=9V DG Refer to measurement procedures - 30+3%
Differential phase V
CC=9V DP Refer to measurement procedures - 3 0 +3 deg
Total harmonic distortion ratio THD Refer to measurement procedures 0.03 0.3 %
Output dynamic range V
D Refer to measurement procedures 3.5 3.8 V
Output offset voltage V
OFF Refer to measurement procedures ±15 mV
Cross talk C
T Refer to measurement procedures - 70 - 60 dB
SW input voltage H V
IH Refer to measurement procedures 2.1 V
SW input voltage L V
IL Refer to measurement procedures 0.7 V
Input impedance Zi 15 kΩ
Output impedance Zo 75 Ω
*
Board size 100mm 100mm t=1.6
MM1501
Item Symbol Measurement conditions Min. Typ. Max. Unit
Consumption current I
CC Refer to measurement procedures 4.7 6.1 mA
Input pin voltage V
IN No-signal, no-load 1.70 1.90 2.10 V
Output pin voltage V
OUT No-signal, no-load 2.10 V
Voltage gain G
V Refer to measurement procedures 5.5 6.0 6.5 dB
Frequency characteristic fc Refer to measurement procedures
- 10+1dB
Differential gain V
CC=9V DG Refer to measurement procedures - 30+3%
Differential phase V
CC=9V DP Refer to measurement procedures - 3 0 +3 deg
Total harmonic distortion ratio THD Refer to measurement procedures 0.03 0.3 %
Output dynamic range V
D Refer to measurement procedures 3.5 3.8 V
Output offset voltage V
OFF Refer to measurement procedures ±30 mV
Cross talk C
T Refer to measurement procedures - 70 - 60 dB
SW input voltage H V
IH Refer to measurement procedures 2.1 V
Sw input voltage L V
IL Refer to measurement procedures 0.7 V
Input impedance Zi 15 kΩ
Output impedance Zo 12 Ω
MM1502
AVR7200 harman/kardon
124
