Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
FRONT PCB
C119 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C131 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C132 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C133 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C134 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C135 1036482071 1 PC CPF 47N0F +10% 100.0V
C137 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C138 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C142 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C143 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C300 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C301 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C302 3093623071 1 PC CC 100P0F +5% -5% 50.0V NP0
C303 3093623071 1 PC CC 100P0F +5% -5% 50.0V NP0
C304 8043459071 1 PC CC 22P0F +5% -5% 50.0V NP0
C305 8043459071 1 PC CC 22P0F +5% -5% 50.0V NP0
C306 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C307 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C308 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C309 2026783030 1 PC CE 47U0F +20% 16.0V 85C 20251640
C310 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C311 1500213030 1 PC CE 10U0F +20% 16.0V 85C
C312 5517937071 1 PC CPM 18N0F +5% 100.0V
C313 5517937071 1 PC CPM 18N0F +5% 100.0V
C316 5517939071 1 PC CPM 3N3F +5% 100.0V
C317 5517939071 1 PC CPM 3N3F +5% 100.0V
C318 5517937071 1 PC CPM 18N0F +5% 100.0V
C319 5517937071 1 PC CPM 18N0F +5% 100.0V
Semiconductors
D107 55179310NR 1 PC D-LEM RED/GREEN 3PIE RD RND CL
D108 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D109 55179310NR 1 PC D-LEM RED/GREEN 3PIE RD RND CL
D120 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D700 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D701 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D702 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D703 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D704 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D705 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D706 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D707 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D708 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D709 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D710 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D711 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D712 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D713 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D714 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D715 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D716 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D717 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D718 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D719 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D720 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D721 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D722 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D723 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D724 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D725 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D726 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D727 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D728 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D730 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D731 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D732 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
29
AVR7200 harman/kardon
