Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
FRONT PCB
D733 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D734 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D735 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D736 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D737 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D738 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D739 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D740 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D741 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D742 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D743 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D744 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D745 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D746 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D747 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D748 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D749 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D750 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D751 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D752 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D753 55199400NR 1 PC D-LEM CT-3SGTA GN RND 3.0 CL 60M0CD
D800 55179330NR 1 PC D-LEM RED/GREEN 5 RD RND CL
D100 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D101 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D102 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D103 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D104 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D105 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D106 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D112 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D113 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D114 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D115 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D116 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D117 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
D119 2049651085 1 PC D-SLP 1SS355 35.0V 225MI0A
IC10 55690010MS 1 PC IC-MICROCONT CXP82860-386Q MAIN AVR7200
IC11 20718660MT 1 PC IC-LOGIC BU4094BF SHIFT REGISTER CMOS
IC12 20718660MT 1 PC IC-LOGIC BU4094BF SHIFT REGISTER CMOS
IC13 20718660MT 1 PC IC-LOGIC BU4094BF SHIFT REGISTER CMOS
IC14 20718660MT 1 PC IC-LOGIC BU4094BF SHIFT REGISTER CMOS
IC15 55087180MT 1 PC IC-LOGIC BU4051BCF MULTIPLEXER HCT
IC30 55142610MT 1 PC IC-OPERAMP NJM2068M DUAL OP
IC16 55179630NR 1 PC PHOTCOUP PC-17T1 PHOTOCOUPLER DIP4
Q102 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q103 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q104 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q105 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q106 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q107 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q108 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q109 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q110 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q111 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q112 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q113 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q114 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q115 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q700 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q701 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q702 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q703 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q704 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q705 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q706 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q707 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q708 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
