Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
FRONT PCB
Q709 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q710 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q711 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q712 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q713 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q714 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q715 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q716 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q717 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q718 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q719 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q720 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q721 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q722 5513333092 1 PC TR-SSD DTC114TKA N 10K0 OHM
Q800 5513318092 1 PC TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM
Q100 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q101 5513335056 1 PC TR-SLPLF MPSA56 Y P -500MI0A -300V
Q116 5517922056 1 PC TR-SLPSWA KRA107M P
RM10 55155930MU 1 PC IC-REMOTE RPM6938-RSIP-A3 RECEIVER 38KHZ
Resistors
R100 1013529091 1 PC RMGCFMIC 68K0 OHM +5% 62MI5W
R101 1013529091 1 PC RMGCFMIC 68K0 OHM +5% 62MI5W
R102 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R103 1013441091 1 PC RMGCFMIC 10R0 OHM +5% 62MI5W
R104 1013522091 1 PC RMGCFMIC 47K0 OHM +5% 62MI5W
R105 1013534091 1 PC RMGCFMIC 100K0 OHM +5% 62MI5W
R106 1013600091 1 PC RMGCFMIC 8K2 OHM +5% 62MI5W
R108 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R109 1013483091 1 PC RMGCFMIC 220R0 OHM +5% 62MI5W
R110 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R111 1013491091 1 PC RMGCFMIC 470R0 OHM +5% 62MI5W
R112 1013491091 1 PC RMGCFMIC 470R0 OHM +5% 62MI5W
R113 1013489091 1 PC RMGCFMIC 390R0 OHM +5% 62MI5W
R114 1013489091 1 PC RMGCFMIC 390R0 OHM +5% 62MI5W
R115 1013491091 1 PC RMGCFMIC 470R0 OHM +5% 62MI5W
R116 1013491091 1 PC RMGCFMIC 470R0 OHM +5% 62MI5W
R117 1013489091 1 PC RMGCFMIC 390R0 OHM +5% 62MI5W
R118 1013489091 1 PC RMGCFMIC 390R0 OHM +5% 62MI5W
R119 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R120 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R121 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R122 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R123 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R124 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R126 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R127 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R128 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R129 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R130 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R131 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R132 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R133 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R134 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R135 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R136 1013501091 1 PC RMGCFMIC 10K0 OHM +5% 62MI5W
R137 1013594091 1 PC RMGCFMIC 4K7 OHM +5% 62MI5W
R140 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R141 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R142 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R145 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R146 1013474091 1 PC RMGCFMIC 100R0 OHM +5% 62MI5W
R147 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R148 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R149 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
R150 1013577091 1 PC RMGCFMIC 1K0 OHM +5% 62MI5W
