Harman Kardon AVR 7200 Service Manual

55 5563715
0
1 PC CONN-SPE SPEAKER TER'BOARD(2P) RD/BK D/N B30290111N FE 19M
M
56 5563716
0
1 PC CONN-SPE SPEAKER TER'BOARD(2P) GY/BK D/N B30290115N FE 19MM
57 5563721
0
1 PC CONN-SPE SPEAKER TER'BOARD(4P) GN/BK/TAN/BK B30490163N FE 19MM
59 5557742
0
1PC
A
C PUN BRACKET SUPPLY --
60 5557741
0
1PC
A
C PUN BRACKET H/SINK BRIDGE --
61 5530405
0
1PC
A
C METAL HEATSINK BRIDGE 34.4*28.5*64H -
-
62 5517063
0
1 PC D-BRDHC BP3504WF 35.0
A
63 5557744
0
1PC
A
C HEATSINK POWER 4CH AVR8200
64 5524637
0
1 PC CON PHONO SCKT RCA 1P W/GND JE010003LN OG
65 5512544
0
1 PC D-LEM TOTX178B RD RND C
L
66 5512543
0
2 PC D-LEM TORX178B RD RND C
L
67 5519160
0
1 PC CON PHONO SCKT RCA 2P W/GNDCAP JW-1502SN OO
68 5519142
0
1 PC CON PHONO SCKT RCA 4P JW-4104RSA
69 5519145
0
1 PC CON PHONO SCKT RCA 4P JW-4104RSC
70 5555451
0
1 PC CONN-SPE 87204-6063 WITH DUST COVER FE 2.77MM 9 -- 0 0
72 5542605
0
1 PC JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C
73 5517633
0
5 PC CON PHONO SCKT RCA 4P JW4104RS GND
74 5523126
0
4 PC SCREW-SPEC 6MM 34MM -- 53 0 0
75 5543608
0
1 PC CON PHONO SCKT RCA 9P JW-4109RS RD,RD,RD,BU,BU,BU,GN,GN,GN
76 5514952
0
7 PC CON DIN SCKT MIX SOCKET RCA-118JP1S
77 5557734
0
4 PC SCREW-SPEC 6MM 15MM -- 53 0 0
78 5531714
0
1 PC CON PHONO SCKT RCA 4P JW-4104RA GN,BN,PP,TA
79 5531713
0
1 PC CON PHONO SCKT RCA 4P JW-4104RC WH,BU,RD,GA
80 5517642
0
1PC
A
C PUN BRACKET BKT GROUND ET 0.5T AVR520
81 5517639
0
3 PC CON PHONO SCKT STEREO JACK JW350S
82 5557735
0
4 PC SCREW-SPEC 6MM 75.1MM -- 53 0 0
83 5519455
0
4PC
A
C HEATSINK 60*20*50H AL6063S-T5 -- M
E
84 5570344
0
1 PC MAIN POWER X FORMER
85 5557687
0
1PC
A
C CPL REAR PANEL AVR720
0
86 5523154
0
1 PC CONN-SPE A206D0054P AC OUTLET US NA 15.25MM 3 BK 0 A
0
87 5564566
0
1PC
A
C PUN BRACKET TRANS BOTTOM AVR7200/8200 --
88 5522202
0
2PC
A
C PUN BRACKET AC INLET
89 5522201
0
1 PC CON MAINS INLET A/C INLET 7014-NGP
90 5517774
0
1PC
A
C DEC KNOB MAIN HIPS AVR8000
91 5557694
0
1PC
A
C PRI LABEL BARCODE AVR720
0
92 5561505
0
1 PC EPR TUNER MODULE
93 5517478
0
1PC
A
C PRI LABEL DATE
94 5557692
0
1PC
A
C PRI LABEL SERIAL AVR7200
95 5544536
0
4PC
A
C FOOT HIPS 94HB ROUND 15.8MM 50MM NOT DEFINED Y DIA
96 5517476
0
4PC
A
C FOOT RUBBER ROUND 3.0MM 25.0MM JIS 60 Y DIA
S1 5512707
0
65 PC SCREW-ST 3MM 10MM JIS B 1122 19 0 0
S2 5512712
0
45 PC SCREW-ST 3MM 8MM JIS B 1122 53 0 0
S3 5512709
0
20 PC SCREW-ST 4MM 8MM JIS B 1122 25 0 0
S4 5516480
0
2 PC SCREW 3MM 8MM DIN963 62 2182 B7
S5 5523125
0
11 PC SCREW-ST 4MM 8MM D020400800 53 0 0
S6 5512729
0
1 PC SCREW-ST 3MM 18MM
S7 5517832
0
63 PC SCREW-ST 3MM 12MM JIS B 1122 53 0 A4
S8 5568418
0
4 PC SCREW-SAM 4MM 12MM
SG 5513546
0
66 PC SCREW-SPEC 3MM 10MM JIS 27 0 0
W1 5512730
0
63 PC WASHER-SPR 3.1MM 6.2MM 0.8MM Y 53 0 I4
W2 5512731
0
28 PC WASHER 3.3MM 8.0MM 0.5MM Y 53 0 A4
W3 5513155
0
4 PC WASHER-SPR 4.2MM 7.2MM 1.0MM N/A 53 0 0
W
4
5513173
0
4 PC WASHER 4.8MM 12MM 1.0MM -- 53 0 I5
AVR7200 harman/kardon
20
