Harman Kardon AVR 7200 Service Manual

EXACT SCREW LOCATIONS
S1 55127070 3X10 B AL PANEL 4 4
FRONT PCB 16 20
PHONE JACK 2 22
STANDBY PCB 2 24
BKT SHIELD DIGITAL 2 26
POWER SW 2 28
F/CH+MAIN CH 8 36
F/CH+TRANS BTM 2 38
F/CH+H/SINK 4 42
BKT SIDE+F/CH 4 46
BKT TOP+F/CH 2 48
M/CH+FOOT 4 52
BKT BRIDGE 1 53
3CH BKT H/SINK 7 60
4CH BKT H/SINK 8 68
H/SINK TR (MAIN PCB) 8 8
BKT AC INLET(SUPPLYPCB) 2 10
S2 55127120 W3X8 Y F/PANEL+F/CH 7 7
3CH AMP PCB 7 14
4CH AMP PCB 8 22
SUPPLY PCB 6 28
POSISTER(3 CH 1, 4 CH 1) 2 30
S3 55127090 W4X8 B TOP COVER 10 10
M/CH+H/SINK 6 16
M/CH+T/BTM 4 20
S4 55164800 BM3X8 POWER SW+BKT 2 2
S5 55231250 BM4X8 MAIN CONDENSOR 6 6
BKT BRIDGE H/SINK 1 7
DSP PCB 4 11
S6 55127290 3X18 BRIDGE DIODE+ H/SINK 1 1
S7 55178320 3X12 3CH H/SINK 27 27
4CH H/SINK 36 63
3CH H/SINK TR 2 65
S8 55684180 4X12 TRANS+NUT 4 4
SG 55135460 GROUND 3CH H/SINK 2 2
4CH H/SINK 2 4
MAIN 10 14
AMP 14 28
DSP 7 35
PROCESSOR 5 40
VIDEO 9 49
TUNER 2 51
MAIN 3 54
OUTLET 2 56
INLET 2 58
TOP COVER 8 66
W1 55127300 SPRING 3 3CH AMP TR IC 27 27
4CH AMP TR IC 36 63
3 CH H/SINK TR 2 65
MAIN PCB H/SINK 8 73
W2 55127310 WASHER 3 3CH AMP TR IC 12 12
4CH AMP TR IC 16 28
BRIDGE 1 29
W3 55131550 SPRING 4 TRANS 4 4
W4 55131730 WASHER 4 TRANS 4 4
N1 55309350 NUT 4 4
