Ref
Designator
Part Number Qty Description
POWER SUPPL
Y
C472 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C473 2025267030 1 PC CE 470U0F +20% 10.0V 85C
C474 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C475 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C476 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C483 5509541071 1 PC CPM 220N0F +10% 63.0V
C484 1307454030 1 PC CE 100U0F +20% 50.0V 85C
C485 2026888030 1 PC CE 10U0F +20% 50.0V 85C
C486 2026884030 1 PC CE 1U0F +20% 50.0V 85C
C495 1036482071 1 PC CPF 47N0F +10% 100.0V
C496 1036482071 1 PC CPF 47N0F +10% 100.0V
C497 1036482071 1 PC CPF 47N0F +10% 100.0V
C290 2029347016 1 PC CC 100N0F +80% -20% 50.0V F
C468 2029347016 1 PC CC 100N0F +80% -20% 50.0V F
C487 2029347016 1 PC CC 100N0F +80% -20% 50.0V F
C491 2073760016 1 PC CC 2N2F +80% -20% 16.0V 3F4
C492 2073760016 1 PC CC 2N2F +80% -20% 16.0V 3F4
C493 2029347016 1 PC CC 100N0F +80% -20% 50.0V F
C494 2029347016 1 PC CC 100N0F +80% -20% 50.0V F
Semiconductors
D451 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D452 55170630NR 1 PC D-BRDHC BP3504WF 35.0A
D453 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D454 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D455 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D456 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D457 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D460 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D465 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D466 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D467 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D472 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D473 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D478 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D479 20525530NR 1 PC D-SR 1N4003 200.0V 1A
IC41 20361320MU 1 PC IC-REGPOSFXD KIA7806PI NORMAL
IC42 55142790NR 0 PC IC-REGPOSFXD NJM2395F63 NORMAL
IC42 55702130NR 1 PC IC-REGPOSFXD NJM2396F63 NORMAL
Q451 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q452 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q453 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q454 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q455 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q456 5514267056 1 PC TR-SLPLF MPSA06 N 500MI0A
Q460 5513335056 1 PC TR-SLPLF MPSA56 Y P -500MI0A -300V
D291 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D292 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D458 2052696016 1 PC D-ZENER 1N5231B 5.1V 500MI0W
D459 7043654016 1 PC D-SLP 1N4148 100.0V 150E-3A
D475 8044273016 1 PC D-ZENER BZX55B33 33V 500MI0W
D476 2045463016 1 PC D-ZENER 1N5239B 9.1V 500MI0W
Resistors
R450 5518010016 1 PC RA 3M3 OHM +10% 500MI0W
R451 55568350NR 1 PC RW 40R0 OHM +5% 15.0W
R452 55568350NR 1 PC RW 40R0 OHM +5% 15.0W
R455 150227100 1 PC RMOF 10R0 OHM +5% 2.0W
R476 80442780NR 1 PC RMOF 4R7 OHM +5% 2.0W
R479 110616700 1 PC RMOF 12K0 OHM +5% 1.0W
R480 110616700 1 PC RMOF 12K0 OHM +5% 1.0W
R316 1105964016 1 PC RCF 1K0 OHM +5% 250MI0W
R453 4043564016 1 PC RCF 4K7 OHM +5% 250MI0W
R454 4043564016 1 PC RCF 4K7 OHM +5% 250MI0W
R456 1105964016 1 PC RCF 1K0 OHM +5% 250MI0W
