Harman Kardon AVR147 User Manual

TRANSISTOR, REGULATOR IC BLOCK DIAGRAM
TO-92M
1. Emitter
2. Collector
3. Base
1. Emitter
2. Collector
3. Base
KTC2874B
KRA107M
2SA1360O
KTD600KG
KTD1302T
KTC3200GR
KTA1271Y
KTA1268GR
KTC3198Y
KSC2785Y
KRC107M
2SC3423O
1. Emitter
2. Collector
3. Base
TO-126
TO-92
123
123
123
1. Emitter
2. Base
3. Collector
KSA733CYT
TO-92
123
1. INPUT
2. GND
3. OUTPUT
MC7815C MC7805C
TO-220
123
1. GND
2. INPUT
3. OUTPUT
MCNJM7905 MC7915C
TO-220
123
1. Base
2. Collector
3. Emitter
2SB1560
2SD2390
KTA1024Y KSC2316Y
1. Emitter
2. Collector
3. Base
TO-3P
TO-92L
123
123
KRA104MT
KSA1175YT
L7805
L7905
MC7809
NJM7824
L7815
L7915
KRC104M
2SA1360
2SB1647
654
123
1.
2.
3.
4.
5.
6.
Marking: MA
Source 1
Gate 1
Drain 2
Source 2
Gate 2
Drain 1
(S1)
(G1)
(D2)
(S2)
(G2)
(D1)
N-CHANNEL MOS FET ARRAY
µPA672T
1 2 3
SOT-223 PKG (FRONT VIEW)
PIN FUNCTION
1. Adj/Gnd
2. Vout
3. Vin
TO-263 (D2 PKG, FRONT VIEW)
PIN FUNCTION
1. Adj/Gnd
2. Vout
3. Vin
1 2 3
LM1117
REGULATOR
PIN CONFIGURATION
SOT-23 Package
1
2
NC = NO CONNECT
V+
NC (OR V–)
V–
3
TOP
VIEW
AD1580
2SD2560
KTA1267
NJM7908
2SB1559
2SD2389
L7808 NJM7812
178
