AVR147 Electrical Parts List
Ref. Designator Part Number Description Qty
FRONT PCB ASSY CUP11910-1
Capacitors
C714 HCBS1H151KBT CAP , CERAMIC 150UF 50V K 1 EA
C716 CCEA1AH331T CAP , ELECT 330UF 10V 1 EA
C723 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C728 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C729 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z 1 EA
C731 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C735 CCEA1CKS100T CAP , ELECT 10UF 16V 1 EA
C742 HCBS1H223ZFT CAP , CERAMIC 0.02UF 50V Z 1 EA
C793 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C794 HCBS1C222MXT CAP , CERAMIC 2200PF 16V 1 EA
C795 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K 1 EA
C796 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K 1 EA
C882 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C891 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z 1 EA
C892 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z 1 EA
C893 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z 1 EA
C894 CCEA1CKS100T CAP , ELECT 100UF 16V 1 EA
C896 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z 1 EA
C897 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C901 HCBS1H390JT CAP , CERAMIC 39PF 50V Z 1 EA
C903 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V 1 EA
C905 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V 1 EA
Semiconductors
D455 CVD1SS133MT DIODE 1SS133 1 EA
D730 CVD1SS133MT DIODE 1SS133 1 EA
D778 HVD1N5819T DIODE , SCHOTTKY 1N5819 1 EA
Q701 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q722 HVTKRA107MT
TRANSISTOR PNP
KRA107M 1 EA
Q724 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q725 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q738 HVTKRC107MT
TRANSISTOR PNP
KRC107M 1 EA
Q739 HVTKTA1271YT
TRANSISTOR PNP
KTA1271Y 1 EA
IC73 HRVNJL34H380A SENSOR , REMOTE JRC 1 EA
IC75 HVI74ACT04MTR I.C , HEX INVERTER FAIRCHILD 1 EA
Resistors
R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
R718 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R737 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
R747 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R781 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R782 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R783 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R784 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R786 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R787 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R791 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J 1 EA
R892 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R893 CRD20TJ333T RES , CARBON 33K OHM 1/5W J 1 EA
R895 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
52
AVR147 harman/kardon
