Harman Kardon AVR147 User Manual

Ref. Designator Part Number Description Qty
FRONT PCB ASSY CUP11910-1
R920 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
Miscellaneous
L702 HLQ02C100KT COIL , AXAIL 10uH 1 EA
BK71 CMD1A209 BRACKET , FLT BRACKET 1 EA
BK72 CMD1A209 BRACKET , FLT BRACKET 1 EA
BK73 CMD1A209 BRACKET , FLT BRACKET 1 EA
BN81 CWB2C908200BM WIRE ASS'Y WIRE 1 EA
BN84 CWB2B905080EN WIRE ASS'Y WIRE 1 EA
BN85 CWB2B903100EW WIRE ASS'Y WIRE 1 EA
BN88 CWB2B904100EN WIRE ASS'Y WIRE 1 EA
CN72 CJP17GA193ZY WAFER, CARD CABLE (SMD) WAFER 1 EA
CN89 CJP04GB46ZY WAFER WAFER 1 EA
ET03 CMD1A569 BRACKET , PCB BRACKET 1 EA
FIP1 HFLHCA18ML03 F.I.P F.I.P 1 EA
RL45 CSL4A014ZE RELAY (+12V) HANDOUK 1 EA
PCB , FRONT STAND BY
CUP11910-3
CN88 CJP04GB46ZY WAFER WAFER 1 EA
R824 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R825 CRD20TJ681T RES , CARBON 680 OHM 1/5W J 1 EA
R828 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R829 CRD20TJ681T RES , CARBON 680 OHM 1/5W J 1 EA
S701 HST1A020ZT SW , TACT 1A020 1 EA
D723 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLUE) L.E.D 1 EA
D727 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLUE) L.E.D 1 EA
PCB , FRONT POWER (MOMS) SW CUP11910-4
CN86 CJP02GA89ZM WAFER WAFER 1 EA
SW1 CSH1A008ZV SW , PUSH (MOMS) MOMS SWITCH 1 EA
DOWNLOAD PCB (CUP11910-7)
CN47 CJP07GA117ZY TEMP ITEM WAFER 1 EA
IC97 HVIST202EBW IC , RS232C TRANSCEIVER ST 1 EA
SW95 KST1A010Z SW , TACT SWITCH 1 EA
SW98 HSH2B018Z SW , PUSH SWITCH 1 EA
R956 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J 1 EA
C953 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C954 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C957 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
R951 C3A206 WIRE , COPPER SN95/PB5 , 0.6
R952 C3A206 WIRE , COPPER SN95/PB5 , 0.6
JK97 CJJ9W001Z 9P D-SUB FEMALE(RS-232C) SEMCO JACK 1 EA
PCB , FRONT PANEL KEY
CUP11910-2
Capacitors
C719 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K 1 EA
C720 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K 1 EA
C721 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K 1 EA
Resistors
R753 CRD20TF1001T RES , CARBON 1K /1/5W /F 1 EA
R754 CRD20TF1501T RES , CARBON 1.5K /1/5W /F 1 EA
