Ref. Designator Part Number Description Qty
PCB , FRONT PANEL KEY
CUP11910-2
R755 CRD20TF1801T RES , CARBON 1.8K /1/5W /F 1 EA
R756 CRD20TF2701T RES , CARBON 2.7K /1/5W/F 1 EA
R757 CRD20TF3301T RES , CARBON 3.3K /1/5W/F 1 EA
R758 CRD20TF5601T RES , CARBON 5.6K/1/5W/F 1 EA
R759 CRD20TF1001T RES , CARBON 1K /1/5W /F 1 EA
R760 CRD20TF1501T RES , CARBON 1.5K /1/5W /F 1 EA
R761 CRD20TF1801T RES , CARBON 1.8K /1/5W /F 1 EA
R762 CRD20TF2701T RES , CARBON 2.7K /1/5W/F 1 EA
R763 CRD20TF3301T RES , CARBON 3.3K /1/5W/F 1 EA
R764 CRD20TF5601T RES , CARBON 5.6K/1/5W/F 1 EA
R765 CRD20TF7501T RES , CARBON 7.5K/1/5W/F 1 EA
R766 CRD20TF1001T RES , CARBON 1K /1/5W /F 1 EA
R767 CRD20TF1501T RES , CARBON 1.5K /1/5W /F 1 EA
R768 CRD20TF1801T RES , CARBON 1.8K /1/5W /F 1 EA
R769 CRD20TF2701T RES , CARBON 2.7K /1/5W/F 1 EA
Miscellaneous
S702 HST1A020ZT SW , TACT 1A020 1 EA
S703 HST1A020ZT SW , TACT 1A020 1 EA
S704 HST1A020ZT SW , TACT 1A020 1 EA
S705 HST1A020ZT SW , TACT 1A020 1 EA
S706 HST1A020ZT SW , TACT 1A020 1 EA
S707 HST1A020ZT SW , TACT 1A020 1 EA
S708 HST1A020ZT SW , TACT 1A020 1 EA
S709 HST1A020ZT SW , TACT 1A020 1 EA
S710 HST1A020ZT SW , TACT 1A020 1 EA
S711 HST1A020ZT SW , TACT 1A020 1 EA
S712 HST1A020ZT SW , TACT 1A020 1 EA
S713 HST1A020ZT SW , TACT 1A020 1 EA
S714 HST1A020ZT SW , TACT 1A020 1 EA
S715 HST1A020ZT SW , TACT 1A020 1 EA
S716 HST1A020ZT SW , TACT 1A020 1 EA
S717 HST1A020ZT SW , TACT 1A020 1 EA
S718 HST1A020ZT SW , TACT 1A020 1 EA
S719 HST1A020ZT SW , TACT 1A020 1 EA
S720 HST1A020ZT SW , TACT 1A020 1 EA
BN89 CWB2B904100EN WIRE ASS'Y WIRE 1 EA
PCB , VR JACK
CUP11910-6
Capacitors
C805 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1 EA
C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z 1 EA
C820 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C821 CCEA1EH470T CAP , ELECT 47UF 25V 1 EA
C822 CCEA1EH470T CAP , ELECT 47UF 25V 1 EA
C823 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C824 HCBS1H471KBT CAP , CERAMIC 470PF 50V 1 EA
C825 HCBS1H151KBT CAP , CERAMIC 150PF 50V 1 EA
C828 HCBS1H470JT CAP , CERAMIC 47PF 50V 1 EA
C830 HCBS1H473ZFT CAP , CERAMIC 0.047F 50V 1 EA
C841 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C842 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C843 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C855 HCBS1H101KBT CAP , CERAMIC 100PF 50V K 1 EA
C856 HCBS1H101KBT CAP , CERAMIC 100PF 50V K 1 EA
C857 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C862 HCBS1H101KBT CAP , CERAMIC 100PF 50V K 1 EA
C863 HCBS1H101KBT CAP , CERAMIC 100PF 50V K 1 EA
54
AVR147 harman/kardon
