Ref. Designator Part Number Description Qty
PCB , VR JACK
CUP11910-6
C874 HCBS1H101KBT CAP , CERAMIC 100PF 50V K 1 EA
Semiconductors
IC87 HVINJM2068MDTE1
I.C , DUAL OP AMP
JRC 1 EA
D774 CVD1SS133MT DIODE 1SS133 1 EA
D701 CVD52CSBBCEAB2 BLUE L.E.D L.E.D 1 EA
D703 CVD52CSBBCEAB2 BLUE L.E.D L.E.D 1 EA
D705 CVD52CSBBCEAB2 BLUE L.E.D L.E.D 1 EA
Resistors
R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J 1 EA
R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J 1 EA
R708 CRD20TJ820T RES , CARBON 82 OHM 1/5W J 1 EA
R864 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
R865 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R866 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
R871 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R872 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R873 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R874 CRD20TJ471T RES , CARBON 470 OHM 1/5W J 1 EA
R875 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R876 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R877 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R878 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R881 C3A206 WIRE , COPPER SN95/PB5 , 0.6
R882 C3A206 WIRE , COPPER SN95/PB5 , 0.6
R921 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R922 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R923 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R924 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R926 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R934 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
R935 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R936 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R937 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
Miscellaneous
VR74 CSR2A037Z ENCODER ENCODER 1 EA
JK85 CJJ9M003Z JACK , S-VIDEO JACK 1 EA
JK86 CJJ4S023Y JACK , BOARD JACK 1 EA
JW84 CWE8202110RV WIRE ASS'Y WIRE 1 EA
CN84 CJP05GB46ZY WAFER WAFER 1 EA
BN51 CWZAVR147BN51 SHIELD WIRE ASS'Y WIRE 1 EA
BN10 CWZAVR230BN10 WIRE ASS'Y (SHIELD) WIRE 1 EA
BN41 CWZAVR130BN41 WIRE ASS'Y (SHIELD) WIRE 1 EA
BN92 CWB2B905100EN WIRE ASS'Y WIRE 1 EA
PCB , PHONE JACK
CUP11910-5
Capacitors
C807 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C808 HCBS1H181KBT CAP , CERAMIC 180PF 50V Z 1 EA
C809 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C817 HCBS1H100JCT CAP , CERAMIC 10PF 50V 1 EA
C850 HCBS1H471KBT CAP , CERAMIC 470PF 50V 1 EA
C851 HCBS1H471KBT CAP , CERAMIC 470PF 50V 1 EA
55
AVR147 harman/kardon
