Ref. Designator Part Number Description Qty
PCB , PHONE JACK
CUP11910-5
C852 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C866 CCEA1HKS100T CAP , ELECT 10UF 50V 1 EA
C867 CCEA1HKS100T CAP , ELECT 10UF 50V 1 EA
C868 CCEA1EKS470T CAP , ELECT 47UF 25V 1 EA
C869 CCEA1EKS470T CAP , ELECT 47UF 25V 1 EA
C870 HCBS1H681KBT CAP , CERAMIC 680PF 50V K 1 EA
C871 HCBS1H681KBT CAP , CERAMIC 680PF 50V K 1 EA
C872 CCEA1CH331T CAP , ELECT 330UF 16V 1 EA
C873 CCEA1CH331T CAP , ELECT 330UF 16V 1 EA
C889 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
Semiconductors
D784 CVD1SS133MT DIODE 1SS133 1 EA
D785 CVD1SS133MT DIODE 1SS133 1 EA
IC76 HVI74HCU04AFNG I.C , INVERTER TOSHICA 1 EA
IC86 HVINJM4556AL I.C , HEADPHONE, DUAL OP-AMP JRC 1 EA
Q451 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q452 HVTKRA107MT
TRANSISTOR PNP
KRA107M 1 EA
Q454 HVTKRC107MT
TRANSISTOR NPN
KRC107M 1 EA
Q734 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q735 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q736 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Q737 HVTKTC2874BT
TRANSISTOR , MUTE NPN
KTC2874B 1 EA
Resistors
R452 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
R453 CRD20TJ362T RES , CARBON 3.6K OHM 1/5W J 1 EA
R454 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R805 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R806 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R869 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
R896 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R897 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R898 CRD20TJ101T RES , CARBON 100 OHM 1/5W J 1 EA
R899 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R900 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R901 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R902 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
R903 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R904 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R905 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R906 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
R907 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R908 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R909 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R910 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R911 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R912 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
R913 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
R915 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1 EA
R918 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
R919 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
Miscellaneous
JK81 CJJ4M043Y JACK , BOARD JACK 1 EA
JK82 HJSTORX177L MODULE , OPTICAL(RX) OPT JACK(RX) 1 EA
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) JACK 1 EA
JW82 CWE8202300RV WIRE ASS'Y WIRE 1 EA
56
AVR147 harman/kardon
