Ref. Designator Part Number Description Qty
PCB , PHONE JACK
CUP11910-5
JW83 CWE8202150RV WIRE ASS'Y WIRE 1 EA
CN85 CJP03GA19ZY WAFER, STRAIGHT, 3PIN WAFER 1 EA
CN92 CJP05GA19ZY WAFER, STRAIGHT, 5PIN WAFER 1 EA
BN18 CWZAVR125BN18 WIRE ASS'Y (SHIELD) WIRE 1 EA
BN22 CWZAVR145BN22 WIRE ASS'Y (SHIELD) WIRE 1 EA
MAIN PCB/HEATSINK
(CUP11911)
Capacitors
C501 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C502 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C503 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C504 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C505 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V 1 EA
C507 HCBS1H331KBT CAP , CERAMIC 330PF 50V 1 EA
C508 HCBS1H331KBT CAP , CERAMIC 330PF 50V 1 EA
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V 1 EA
C510 HCBS1H331KBT CAP , CERAMIC 330PF 50V 1 EA
C561 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C562 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C563 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C564 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C565 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C566 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C567 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C568 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C569 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C570 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C571 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1 EA
C572 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1 EA
C573 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1 EA
C574 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1 EA
C575 HCBS1H681KBT CAP , CERAMIC 680PF 50V 1 EA
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V 1 EA
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V 1 EA
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V 1 EA
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V 1 EA
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V 1 EA
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V 1 EA
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V 1 EA
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V 1 EA
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V 1 EA
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V 1 EA
C681 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C682 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C683 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C684 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C685 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C726 CCKT1H221KB CAP , CERAMIC 220PF 50V 1 EA
C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V 1 EA
C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V 1 EA
C905 CCFT1H223ZF CAP , CERAMIC 0.022UP 50V 1 EA
C907 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
C908 CCFT1H223ZF CAP , CERAMIC 0.022UP 50V 1 EA
C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V 1 EA
C911 CCEA1CH471T CAP , ELECT 470UF 16V 1 EA
C912 CCEA1CH221T CAP , ELECT 220UF 16V 1 EA
C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1 EA
C914 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
57
