Harman Kardon AVR147 User Manual

Ref. Designator Part Number Description Qty
MAIN PCB/HEATSINK
(CUP11911)
C917 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C924 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1 EA
C939 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
C940 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C948 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF 1 EA
C949 CCEA1HH220T CAP , ELECT 22UF 50V 1 EA
C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V 1 EA
C972 HCQI1H562JZT CAP , MYLAR 5600PF 50V 1 EA
C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V 1 EA
C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V 1 EA
C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V 1 EA
C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C991 CCEA1HH1R0T CAP , ELECT 1UF 50V 1 EA
C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
C999 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V ZF 1 EA
C631 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C632 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C633 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C634 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C635 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C636 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C637 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C638 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C639 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C640 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
C902 CCET50VKL4682NK CAP , ELECT 6800UF/50V 1 EA
C904 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV 1 EA
C906 CCEA1EH102E CAP , ELECT 1000UF 25V 1 EA
C909 CCET50VKL4682NK CAP , ELECT 6800UF/50V 1 EA
C915 CCET50VKL4682NK CAP , ELECT 6800UF/50V 1 EA
C916 CCET50VKL4682NK CAP , ELECT 6800UF/50V 1 EA
Semiconductors
D501 CVD1SS133MT DIODE 1SS133 1 EA
D502 CVD1SS133MT DIODE 1SS133 1 EA
D503 CVD1SS133MT DIODE 1SS133 1 EA
D504 CVD1SS133MT DIODE 1SS133 1 EA
D505 CVD1SS133MT DIODE 1SS133 1 EA
D581 CVD1SS133MT DIODE 1SS133 1 EA
D582 CVD1SS133MT DIODE 1SS133 1 EA
D583 CVD1SS133MT DIODE 1SS133 1 EA
D584 CVD1SS133MT DIODE 1SS133 1 EA
D585 CVD1SS133MT DIODE 1SS133 1 EA
D901 CVD1N4003SRT RECT , DIODE 1N4003 1 EA
D902 CVD1SS133MT DIODE 1SS133 1 EA
D911 CVD1SS133MT DIODE 1SS133 1 EA
D912 CVD1SS133MT DIODE 1SS133 1 EA
D914 CVD1SS133MT DIODE 1SS133 1 EA
D917 CVD1SS133MT DIODE 1SS133 1 EA
D953 CVD1SS133MT DIODE 1SS133 1 EA
D954 CVD1N4003SRT RECT , DIODE 1N4003 1 EA
D955 CVD1N4003SRT RECT , DIODE 1N4003 1 EA
D956 CVD1N4003SRT RECT , DIODE 1N4003 1 EA
D957 CVD1N4003SRT RECT , DIODE 1N4003 1 EA
D961 CVD1N4003ST RECT , DIODE 1N4003 1 EA
D962 CVD1N4003SRT RECT , DIODE 1N4003 1 EA
D963 CVD1N4003ST RECT , DIODE 1N4003 1 EA
58
AVR147 harman/kardon
