Ref. Designator Part Number Description
FRONT PCB ASS'Y
S709 HST1A020ZT SW , TACT
S710 HST1A020ZT SW , TACT
S711 HST1A020ZT SW , TACT
S712 HST1A020ZT SW , TACT
S713 HST1A020ZT SW , TACT
S714 HST1A020ZT SW , TACT
S715 HST1A020ZT SW , TACT
S716 HST1A020ZT SW , TACT
S717 HST1A020ZT SW , TACT
S718 HST1A020ZT SW , TACT
S719 HST1A020ZT SW , TACT
S720 HST1A020ZT SW , TACT
BAT1 HABGP40BVH3A3H BATTERY , RECHARGEABLE GP40BBVH3A3H
BK71 CMD1A209 BRACKET , FLT A4-92-1739
BK72 CMD1A209 BRACKET , FLT A4-92-1739
BK73 CMD1A387 BRACKET , PCB
BK74 CMD1A209 BRACKET , FLT A4-92-1739
BN10 CWZAVR230BN10 WIRE ASS'Y (SHIELD)
BN15 CWB2B906150EN WIRE ASS'Y
BN16 CWZAVR2550BN16 WIRE ASS'Y (SHIELD)
BN18 CWZAVR125BN18 WIRE ASS'Y (SHIELD)
BN41 CWZAVR130BN41 WIRE ASS'Y (SHIELD)
BN80 CWB2B911420EW WIRE ASS'Y
BN81 CWB2B908250BM WIRE , ASS'Y
BN84 CWB2B905080EN WIRE ASS'Y
BN85 CWB2B902090EN WIRE ASS'Y
BN87 CWZAVR2550BN87 WIRE ASS'Y (SHIELD)
BN88 CWB2B904070EN WIRE ASS'Y
BN89 CWB2B905080EN WIRE ASS'Y
BN90 CWB2B902090EN WIRE ASS'Y
BN94 KJP13GB99ZM CONNECTOR MOLEX35237-1310
BN95 KJP08GB99ZM CONNECTOR , HOUSING MOLEX35237-0810
CN10 KJP04GB46ZM WAFER MOLEX 53015
CN11 KJP15GA98ZM WAFER MOLEX35336-1510
CN12 KJP15GA98ZM WAFER MOLEX35336-1510
CN15 KJP06GA19ZM WAFER MOLEX53014-0610
CN16 KJP08GB46ZM WAFER
CN72 KJP32GA161ZY WAFER YD200 SERIES
CN79 KJP05GA19ZM WAFER MOLEX53014-0510
CN82 KJP06HA37ZM WAFER MOLEX42140-2206
CN84 KJP05GA19ZM WAFER MOLEX53014-0510
CN85 KJP02GA19ZM WAFER
CN86 KJP02GA89ZM WAFER MOLEX35328-02
CN87 KJP06GA19ZM WAFER MOLEX53014-0610
CN88 KJP04GA19ZM WAFER
CN89 KJP05GA19ZM WAFER MOLEX53014-0510
CN90 KJP02GA19ZM WAFER
CN91 KJP06HA37ZM WAFER MOLEX42140-2206
JK81 CJJ4M041Y JACK , BOARD (COAX)
JK82 HJSTORX179L MODULE , OPTICAL(RX) TORX179L
JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE)
JK85 CJJ9M003Z JACK , S-VIDEO
JK86 CJJ4S023Y JACK , BOARD
JW82 CWZAVR2550JW82 WIRE , ASS'Y
JW84 CWE8202110RV WIRE, ASS'Y
JW85 CWE8202070AA WIRE ASS'Y
SW01 CSH1A008ZV SW , PUSH (MOMS)
X701 HOX05000E160C CRYSTAL 5 MHz
X703 HOX10000E220C CRYSTAL 10 MHz
CTB3+10G SCREW
CTB3+16GFZ SCREW
AVR330 harman/kardon
38
