Harman Kardon AVR330 User Manual

Ref. Designator Part Number Description
FRONT PCB ASS'Y
CTWS3+10G SCREW
KBC1A147MBZC22 KNOB , MOMS AVR130/230/330
KBT1A903MMZC22 KNOB , POWER
KBT1A904MBZC22 KNOB , SET AVR130/230/330
KBT1A905MBZC22 KNOB , FUNCTIION AVR130/230/330
KHR301 CLAMPER
BN72 CWZAVR230BN72 WIRE ASS'Y
CKC1B145S46 CABINET , TOP AVR130/230/330
CLZ9Z028Z FERRITE CORE(21.2X6.4X12.7) K5C T
CMH1A214 HOLDER , VOLUME AVR130/230/330
CMZ1A090 SHEET , VOLUME AVR130/230/330
CTB3+8JFC SCREW
CTB4+6FFC SCREW
MAIN PCB ASS'Y
Capacitors
C501 HCEA1VH100T CAP , ELECT 10UF 35V
C502 HCEA1VH100T CAP , ELECT 10UF 35V
C503 HCEA1VH100T CAP , ELECT 10UF 35V
C504 HCEA1VH100T CAP , ELECT 10UF 35V
C505 HCEA1VH100T CAP , ELECT 10UF 35V
C506 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C507 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C508 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C509 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C510 CCKT1H331KB CAP , CERAMIC 330PF 50V KB
C561 HCEA1CH101T CAP , ELECT 100UF 16V
C562 HCEA1CH101T CAP , ELECT 100UF 16V
C563 HCEA1CH101T CAP , ELECT 100UF 16V
C564 HCEA1CH101T CAP , ELECT 100UF 16V
C565 HCEA1CH101T CAP , ELECT 100UF 16V
C566 HCEA1CH101T CAP , ELECT 100UF 16V
C567 HCEA1CH101T CAP , ELECT 100UF 16V
C568 HCEA1CH101T CAP , ELECT 100UF 16V
C569 HCEA1CH101T CAP , ELECT 100UF 16V
C570 HCEA1CH101T CAP , ELECT 100UF 16V
C571 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C572 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C573 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C574 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C575 HCBS1H681KBT CAP , CERAMIC 680PF 50V
C601 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C602 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C603 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C604 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C605 CCCT1H120JC CAP , CERAMIC 12PF 50V JC
C606 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C607 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C608 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C609 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C610 CCCT1H330JC CAP , CERAMIC 33PF 50V JC
C681 HCEA1HH100T CAP , ELECT 10UF 50V
C682 HCEA1HH100T CAP , ELECT 10UF 50V
C683 HCEA1HH100T CAP , ELECT 10UF 50V
C684 HCEA1HH100T CAP , ELECT 10UF 50V
C685 HCEA1HH100T CAP , ELECT 10UF 50V
C721 CCKT1H221KB CAP , MYLAR 220PF 50V KB
C722 CCKT1H221KB CAP , MYLAR 220PF 50V KB
AVR330 harman/kardon
39
