INSTALLATION AND CONNECTIONS 15
INSTALLATION AND CONNECTIONS
your television so that you may take advantage of
the fact that the remote control is preprogrammed
with television product codes for the Video 3
device.
IMPORTANT: If you are only using the tel-
evision as a display device (i.e., if you receive your
television programs through a cable box or satellite
receiver), do not connect the TV’s outputs to the
Video 3 Audio/Video and S-Video Input Jacks
, or to any other inputs on the AVR 335.
4. Connect the analog audio and video outputs of
a DVD or laser disc player to the
DVD Audio/
Video and S-Video Inputs
e .
5. Connect the digital audio outputs of a DVD player,
satellite receiver, cable box or HDTV converter to
the appropriate
Optical or Coaxial Digital Inputs
dg*(.
6. Connect the
Video and/or S-Video Monitor
Output
c jacks on the receiver to the com-
posite or S-video input of your television monitor
or video projector.
7. If your DVD player and monitor both have
component video connections, connect the com-
ponent outputs of the DVD player to the
DVD
Component Video Inputs
›. Even when com-
ponent video connections are used, the audio con-
nections should still be made to either the analog
DVD Audio Inputs or any of the Optical or
Coaxial Digital Input Jacks dg*(.
8. If another device with component video outputs is
available, connect it to the
Video 2 Component
Video Inputs
‹. The audio connections for this
device should be made to either the
Video 2
Audio Inputs
or any of the Optical or
Coaxial Digital Input Jacks dg*(
.
9. If the component video inputs are used, connect
the
Component Video Monitor Outputs ‹ to
the component video inputs of your TV, projector
or display device.
10. If you have a camcorder, video game or other
device that is connected to the AVR on a tempo-
rary rather than permanent basis, connect its
audio, video and digital audio outputs to the
Front-Panel Inputs *(ÓÔ. A device
connected here is selected as the Video 4 input,
and the digital inputs must be assigned to the
Video 4 input. (See page 17 for more information
on input configuration.)
Video Connection Notes:
• When the component video jacks are used, the on-
screen menus are not visible and you must switch
to the standard composite or S-video input on your
TV to view them.
• The AVR 335 will accept either standard composite,
S-video or Y/Pr/Pb component video signals.
However, it will not convert any of these signals do
a different format.
• When connecting a video source to the AVR 335,
you may use composite, component or S-video,
but only one type of video may be connected for
each device.
• When more than one video format is used, it is
necessary to make a separate connection from
the AVR to your video display for each format.
For example, if both composite and component
sources are connected to the AVR 335, both the
Composite and Component Video Monitor
Outputs
‹ must be connected to the appro-
priate inputs on your video display.
System and Power Connections
The AVR 335 is designed for flexible use with multi-
room systems, external control components and
power amplifiers.
Main Room Remote Control Extension
If the receiver is placed behind a solid or smoked
glass cabinet door, the obstruction may prevent the
remote sensor from receiving commands. In this
event, an optional remote sensor may be used.
Connect the output of the remote sensor to the
Remote IR Input ¢ jack.
If other components are also prevented from receiving
remote commands, only one sensor is needed. Simply
use this unit’s sensor or a remote eye by running a
connection from the
Remote IR Output § jack to
the Remote IR Input jack on Harman Kardon or other
compatible equipment.
Multiroom IR Link
The remote room IR receiver should be connected to
the AVR 335 via standard coaxial cable. Plug the IR con-
nection cable into the
Multiroom IR Input ∞ jack on
the AVR 335’s rear panel.
If Harman Kardon-compatible source equipment is part
of the main room installation, the
Remote IR
Output
§ jack on the rear panel should be connected
to the
IR IN jack on source equipment. This will enable the
remote room sensor to control that equipment.
Multiroom Connections
The AVR 335 is equipped with multizone capabilities
that allow it to send a separate audio source to the
remote zone from the one selected for use in the
main room.
Depending on your system’s requirement, three
options are available for audio connection:
Option 1: Use high-quality, shielded audio intercon-
nect cable from the AVR 335’s location to the remote
room. In the remote room, connect the interconnect
cable to a stereo power amplifier. The amplifier will be
connected to the room’s speakers. At the AVR 335,
plug the audio interconnect cables into the
Multiroom
Audio Output
¡ jacks on the AVR 335’s rear panel.
Option 2: Connect the Multiroom Audio Output ¡
jacks on the AVR 335 to the inputs of an optional
stereo power amplifier. Run high-quality speaker wire
from the amplifier to the speakers in the remote room.
Option 3: Taking advantage of the AVR 335’s built-in
seven-channel amplifier, it is possible to use two of the
amplifier channels to power speakers in the remote
room. When using this option you will not be able to
use the full 7.1-channel capabilities of the AVR 335 in
the main listening room, but you will be able to add
another listening room without additional external
power amplifiers. To use the internal amplifiers to
power a remote zone, connect the speakers for
the remote room location to the
Surround Back/
Multiroom Speaker Outputs
‚. Before using the
remote room you will need to configure the amplifiers
for surround operation by changing a setting in the
MULTIROOM menu, following the instructions
shown on page 35.
NOTE: For all options, you may connect an optional
IR sensor in the remote room to the AVR 335 via an
appropriate cable. Connect the sensor’s cable to the
Multiroom IR Input ∞ and use the Zone II remote
to control the room volume. Alternatively, you may
install an optional volume control between the output
of the amplifiers and the speakers. See page 35 for
more informatin on the multiroom system.
AC Power Connections
This unit is equipped with two accessory AC outlets.
They may be used to power accessory devices, but
they should not be used with high-current-draw equip-
ment such as power amplifiers. The total power draw
to each outlet may not exceed 100 watts.
The
Switched AC Accessory Outlet ° will receive
power only when the unit is on. This is recommended
for devices that have no power switch or a mechanical
power switch that may be left in the “ON” position.
NOTE: Many audio and video products go into a
Standby mode when they are used with switched out-
lets, and cannot be fully turned on using the outlet
alone without a remote control command.
The
Unswitched AC Accessory Outlet · will
receive power as long as the unit is plugged into a
powered AC outlet.
Once the
AC Power Cord ‡ is connected, you are
almost ready to enjoy the AVR 335!
33
