Harman JBL EON ONE Compact - Audio Outputs; USB Power Ports

11
AUDIO OUTPUTS
The EON ONE Compact provides a 1/4" PASS THRU output for connecting to additional EON ONE Compact
loudspeakers. A 3.5mm (1/8") HEADPHONE output is also provided for additional monitoring options.
USB POWER PORTS
These ports can be used to charge a Bluetooth device or other portable music playback device during use� One
port provides 1A for low-amperage devices and the other provides 2A for USB devices requiring higher current�
USB power capability
TBD�
PASS THRU output can
be connected to the line
input of another JBL
EON ONE Compact to
expand the system for
monitoring or higher
output capabilities
