Harman JBL MS202 - Wall Mounting Guide

12
1. Unscrew the screws to remove the host dock. 2. Punch two holes with a 121 mm spacing in
between on a solid wall.
Wall Mounting Guide
3. Screw in two mounting screws (not provided) and hang the host on the screws.
Note: Use two inflatable colloidal particles if necessary before screwing the screws in the particles.
121 mm
Solid wall
5 mm
25 -30 mm
