Harman P43 - Automatic Ignition

Harman® • P-Series Installation Manual_R3 • 2014 -___ • 09/1414 3-90-436168i
12"
min. wall to outlet
36"
min. clearance to any
combustible material
#7 Installing through the ceiling
Through the ceiling vent, follow PL vent manufacturers
recommendationswhenusingwallandceilingpassthrough.
Sealpipejointswithsiliconeoraluminumtapeinadditionto
thesealingsystemusedbythemanufacturer.
Note: Do not place joints within wall pass-through.
Figure 4.7
Figure 4.8
Figure 4.9
Area within dotted circle represents the minimum
clearance to combustible materials such as shrubbery,
mulchortallgrasses.
12"
min. above ground level
Minimum ue vent conguration
It is recommended that outside
air be installed with this venting
conguration.
PL vent manufacturer's
restop spacer and support
1" MIN.
No insulation or other
combustible materials
are allowed within 3"
of the PL vent pipe.
ashing
storm collar
1" MIN.
1" MIN.
12" MIN
1” MIN.
