Harman P43 Owner's Manual

Harman® • P-Series Owner’s Manual_R1 • 03/1430 3-90-436168c
Service Parts
P43 Pellet
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT:THISISDATEDINFORMATION.Partsmustbeorderedfromadealerordistributor.
Hearth and Home Technologies does not sell directly to consumers.Providemodelnumber
andserialnumberwhenrequestingservicepartsfromyourdealerordistributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
2 FeederAssembly 1-10-09535A
2.1
PelletFeederGearMotor,4RPM 3-20-60906 Y
2.2
ULFeederCamBearing 3-31-3014 Y
2.3
FeederCrossoverKit 1-00-67900 Y
9MMSiliconeTube 5Ft 1-00-511427 Y
2.4
PelletAirIntakeAssembly 1-10-06810A
2.5
GasketFeederAirIntake Pkgof6 3-44-72224-6 Y
2.6
ULFeederAirIntake 1-10-72222
2.7
GasketUltraAirIntake Pkgof10 3-44-677160-10 Y
2.8
UltraFeederWeldment 1-10-724132 Y
2.9
ULFeederPusherArm 1-10-677187W Y
2.10
FinesDeector No longer available 2-00-677138-10
2.11
Gasket,ULFeeder 1-00-677122 Y
2.12
SlidePlateAssembly 1-10-677121A Y
2.13
ULFeederAugerAssembly 3-50-00565 Y
2.14
BearingFlangew/Hardware 1-00-04035 Y
2.15
ULFeederGearMotorBracketw/Grommet 1-00-247406 Y
2.16
ULFeederCamBlock 3-00-677154 Y
HopperSwitchFeederFitting Pkgof2 1-00-142818 Y
MotorBracketGrommet Pkgof12 3-31-2761-12
PillowBlock Pkgof4 3-31-3614087-4 Y
SiliconeTubing,1/8” 5Ft 1-00-5113574 Y
Additionalservicepartsonfollowingpage.
#2 Feeder Assembly
2.7
2.6
2.5
2.4
2.3
2.2
2.1
2.15
2.16
2.8
2.9
2.10
2.11
2.12
2.13
2.14
