Harman P43 - Page 31

Harman® • P-Series Owner’s Manual_R1 • 03/1431 3-90-436168c
Service Parts
P43 Pellet
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT:THISISDATEDINFORMATION.Partsmustbeorderedfromadealerordistributor.
Hearth and Home Technologies does not sell directly to consumers.Providemodelnumber
andserialnumberwhenrequestingservicepartsfromyourdealerordistributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
3 FlueTailPipe 3-00-247237 Y
4 AugerMotorCover 2-00-773843P Y
5 AugerMotorShield 2-00-773815P Y
6 DifferentialSwitch 3-20-6866 Y
7 DistributionBlower 3-21-33647 Y
8 CombustionBlower 3-21-08639 Y
CombustionBlowerMountingScrews Pkgof100 1-00-53483208
9 RearCoverLeft 2-00-773828-1P Y
10 RearCoverRight 2-00-773828-2P Y
11 CombIntakeWeldment 1-10-08516S Y
12 RetainerAssembly 1-10-08533S Y
13 AshPan 1-10-7738108A Y
14 AshDoorAssembly
Pre008168147 1-10-7738106A
Post008168147 1-10-773904A
WoodHandle Pkgof3 3-40-08746-3
15 BoltonHinge 2-00-06968B
16 CastDoorFrame 4-00-06800P
CastDoorw/Glass 1-10-06800A
17 GlassPanel 3-40-950133647 Y
18
DoorHandleAssembly
1-00-453001 Y
Contains: Handle, 6 mm Washer, SHCS, handle, Elbow, Paw (Cast), SSS, Bhcs.
WoodenHandlew/Hardware,LoadDoor 1-00-00247 Y
19 BurnPotWeldment 1-10-00675 Y
FlameGuide 3-00-03000 Y
CleanOutCover 2Sets 1-00-06623
Y
ThumbScrew Pkgof10 3-31-782108-10 Y
20
FireBrick4-1/2x9x1-1/4” Pkgof7 1-00-900450125 Y
Firebrick,FullSkid 414Pcs 3-40-900450-414
21 HopperHeatShield 2-00-773854B
22 FeederCover 2-00-773826L
23 CircuitBoardw/Knobs&Shafts 1-00-05886 Y
ControlBoardLabel 3-90-07766
CircuitBoardPlate,Studdedw/label 1-10-08327
Knob,ContolBoard/D-Shaft 25Sets 1-00-015605 Y
AirwashO-Rings Pkgof10 1-00-939639
Y
ArrowBurnPotScraper Pkgof10 2-00-773850-10
CradleAssembly
IgniterHolder,Cradle,&FlatBottom
3Sets 1-00-06620
Y
Additionalservicepartsonfollowingpage.
