Harman® • P-Series Owner’s Manual_R1 • 03/149 3-90-436168c
ÉTAT DE
L’ALIMENTATION
VENTILATEUR DE
VENTILATEUR DE
MOTEUR
DISTRIBUTION
COMBUSTION
D’ALIMENTATION
ALLUMEUR
ALLUMEUR
MANUEL
AVERTISSEMENT HAUTE TENSION
Couper le courant avant de retirer le panneau.
AUTO
TEST
OFF
L
I
M
I
T
E
D
’
A
L
I
M
E
N
T
A
T
I
O
N
C
O
M
B
U
S
T
I
O
N
C
O
N
S
T
A
N
T
E
T
E
M
P
A
M
B
I
A
N
T
E
Feed limit
Sets the maximum feed
rate
Test
Runs all motors at full
speed for one minute
to check operation.
Afterwards the
control will simulate
a minimum burn with
the combustion blower
remaining on low.
Distribution Blower
speed adjustment
range.
L=low
H=high
Temp dial
Allows you to adjust the room temperature setting, in
RoomTempMode,usingtheouterscalemarkedin
degrees Fahrenheit. It also allows you to adjust the
constantburnsetting,whileinConstantburnMode,
using the inner scale marked from 1 to 7.
Mode Selector
Allows you to choose between
RoomTempMode,Constantburn
Mode, or OFF.Also allows you to
vary the distribution blower speed
by turning the knob to the high or
low side of each mode.
Power Light
Indicates power to the
control.
Indicates power to the
feed motor.
Indicates power to
combustion blower
Status Light
Will be lit in either stove
or room temp mode
when pointer is not
within off position band
except after normal
shut down. Blinks to
indicate errors listed
below.
Indicates power to
distribution blower.
Dealer Diagnostic Port
For dealer maintenance
only. Requires special DDM
monitor supplied to Harman®
Dealersexclusively.
Indicates igniter is on.
Igniter switch
Set to appropriate
Start-Up mode.
C. Control Explanation

Harman P43 Specifications

General

Fuel Type	Pellet
Ignition	Automatic
Thermostat	Yes
Heating Area	Up to 2, 200 sq ft
Blower	Yes
Warranty	Limited
