Quick Reference ( Auto-Light )
1. Turn Mode Selector to OFF.
2. Use shaker handle to clean the heat exchanger tubes.**
3. Scrape the air holes in the burnpot.**
4. Fill the hopper with pellets.
5. Turn Feed Adjuster to “Test”.*
6. Check the Combustion Blower and Feeder Motor for operation.*
7. Turn Feed Adjuster back to the #4 setting.
8. Turn the Wall Control to the desired temperature.
9. Turn all of the Furnace Control knobs to the settings shown.*
10. Flip the Auto-Light switch up.*
The furnace will ignite if the temperature in the room is less than the temperature set on the Wall Control.
*See the section on Operation for information about Manual Lighting and Emergency Power.
**See the section on Maintenance for more details about cleaning.
Temp Dial Mode Selector
“Test”
Wall Control
