Harman PF100 User Manual

3-90-08101R23_06/13
Service Parts
PF100 Pellet
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT:THISISDATEDINFORMATION.Whenrequestingserviceorreplacementpartsfor
yourappliancepleaseprovidemodelnumberandserialnumber.Allpartslistedinthismanualmay
beorderedfromanauthorizeddealer.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
1 HopperAssembly
Pre004350582or008350087 1-10-73329
Post004350582or008350087 1-10-08224A
2
HopperLidAssembly-Swelllatch Pre004350582or008350087 1-10-73333A
HopperLidAssembly-SpringLatch Post004350582or008350087 1-10-73491A
Swelllatch 1-00-199110
Y
SpringCatch 3-31-00927
Y
HopperMuferandFittings 1set 1-00-18186618
Y
HopperLidCatch 2-00-72166B
Hinge,HopperLid 3-31-73325
Gasket,HopperLid 10Ft 1-00-00248
Y
3 FanControl/Highlimit 3-20-23139
Y
4 CombustionBlower 3-21-08639
Y
MountingPlate 1-10-73416
Grommets&Spacers Pkgof25 1-00-960026
FanBlade,FeedMotor Pkgof3 3-20-09302-3
Y
FanBlade,5"SinglePaddle(CombustionBlower) 3-20-40985
Y
FanBlade,5"Double(highaltitude) 3-20-502221
Y
CombBlowerMountingScrews Pkgof100 1-00-53483208
CombBlowerHeatShield 2-00-73339
5 ToggleSwitch-3Speed 3-20-70020
Y
6 Filterboxkit 1-00-20201
7 BottomCover
Front 2-00-73338-15S
Rear 2-00-73340-15S
8 AshDoor 1-10-73323-15A
9 TopCover
Front 2-00-73411-15S
Rear 2-00-73412-15S
10 ShakerCover 2-00-73335-15S
Chain,Shaker 1-10-73354
Additionalservicepartsonfollowingpage.
4/13
Pellet Furnace
1-70-08100
1
3
2
5
6
7
8
9
10
4
