Harman PF100 - Operation - Control System; The Control

21
3-90-08101R23_06/13
The Control
Thecontrolcanbecoveredasshownabove,oruncovered
asshownatleft.Thereisapairofslotsprovidedforeach
position.Simplymovethecovertothedesiredpositionby
placingthetabsonthecoverintheproperslots.
Operation
Fig. 41
Combustion Blower
Combustion Blower Cover
Fan Control
Hopper Lid
Latches
Control Cover
3 Speed Switch
Viewing Glass
Outer Door
Vent Pipe
Heat Exchanger
Cleaning Handle
Outer Door Latches
Filter Box
Hopper
Fig. 40
CAUTION
!
HOT WHILE IN OPERATION. DO NOT TOUCH.
KEEP CHILDREN, CLOTHING, FURNITURE, AND
OTHER COMBUSTIBLE MATERIAL OUT OF THE
INSTALLATION CLEARANCE AREA.
WARNING
!
DO NOT OPERATE WITH FIRE CHAMBER OR ASH
REMOVAL DOORS OPEN.
DO NOT STORE FUEL OR OTHER COMBUSTIBLE
MATERIAL WITHIN INSTALLATION CLEARANCE
AREA.
WARNING
!
