Harman PF100 User Manual

3-90-08101R23_06/13
Service Parts
PF100 Pellet
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
#11 Feeder Assembly Pre SN 004350582 or 008350087
11.3
11.4
11.5
11.6
11.7
11.8
11.9
11.10
11.11
11.12
11.1
11.2
IMPORTANT:THISISDATEDINFORMATION.Whenrequestingserviceorreplacement
partsforyourappliancepleaseprovidemodelnumberandserialnumber.Allpartslisted
inthismanualmaybeorderedfromanauthorizeddealer.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
11 FeederAssembly 1-10-08113A
11.1 AirIntakeDamperAssembly 1-10-06466W
11.2 AirIntakeWeldment 1-10-773843
11.3 FeederWeldment 1-10-677150 Y
11.4 SlidePlateAssembly 1-10-08037 Y
11.5 PusherArmAssembly 1-10-08048 Y
PillowBlock Pkgof4 3-31-3614087-4
Y
11.6 FeedCoverandGasket 2Sets 1-00-677152 Y
11.7 AugerAssembly 3-50-00465 Y
11.8 CamBearing 3-31-3014 Y
11.9 BearingFlangew/Hardware 1-00-04035
Y
11.10 Bracket,GearMotor Pkgof2 1-00-01534 Y
11.11 GearMotor,6RPM 3-20-09302 Y
11.12 CastCamBlock 3-00-00153 Y
FeederRepairKit 1-00-677150 Y
GasketFeederAirIntake Pkgof6 3-44-72224-6
Y
MotorBracketGrommets Pkgof12 3-31-2761-12
Additionalservicepartsonfollowingpage.
