Harman PF100 User Manual

3-90-08101R23_06/13
Service Parts
PF100 Pellet
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT:THISISDATEDINFORMATION.Whenrequestingserviceorreplacement
partsforyourappliancepleaseprovidemodelnumberandserialnumber.Allpartslisted
inthismanualmaybeorderedfromanauthorizeddealer.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
12.1
PelletFeederGearMotor,10RPM 3-20-02524
Y
12.2
ULFeederCam 3-31-3014
Y
12.3
FeederAirCrossoverKit 1-00-67900
Y
9MMSiliconeTube 5Ft 1-00-511427
Y
12.4
PelletAirIntakeAssembly 1-10-06810A
12.5
GasketFeederAirIntake Pkgof6 3-44-72224-6
Y
12.6
ULFeederAirIntake 1-10-72222
12.7
GasketUltraAirIntake Pkgof10 3-44-677160-10
Y
12.8
UltraFeederWeldment 1-10-72226S
Y
12.9
ULFeederPusherArm 1-10-677187W
Y
PillowBlock Pkgof4 3-31-3614087-4
Y
12.10
FinesDeector
No longer available
2-00-677138-10
12.11
Gasket,ULFeederCover 1-00-677122
Y
12.12
SlidePlateAssembly 1-10-677121A
Y
12.13
ULFeederAugerAssembly 3-50-00565
Y
12.14
BearingFlangew/Hardware 1-00-04035
Y
12.15
ULFeederGearMotorBracketw/Grommet 1-00-247406
Y
12.16
ULFeederCamBlock 3-00-677154
Y
Gasket,HopperThroat
Pre004350582or
008350087
3-44-677185 Y
Additionalservicepartsonfollowingpage.
#12 Post Feeder Assembly
SN #004350582 or 008350087
12.7
12.6
12.5
12.4
12.3
12.2
12.1
12.16
12.15
12.8
12.9
12.10
12.11
12.12
12.13
12.14
