Harmar Mobility AL010 - Page 11

Outside Vehicle Lis: Installaon & Service Manual
06DEC19 | P/N: 630-00106 REV A
11
OUTSIDE VEHICLE LIFTS: SECTION 3
PREPARATION
STANDARD APPLICATION
APPLICATION WITH
SWING-AWAY
Class Part# Descripon HV D1 D2 HV D1 D2
Class 3
*AL1236HD  20"—24" " " 18"22" 0"8" "
*AL1238  24"26" " " 22"24" 0"8" "
*AL1238HD  24"26" " " 22"24" 0"8" "
AL124  6"18" " " 6"16" 0"4" "
AL124HD  6"18" " " 6"16" 0"4" "
AL1242  18"20" " " 16"18" 0"4" "
*AL1242HD  18"20" " " 16"18" 0"4" "
*AL1245  20"23" " " 18"21" " "
*AL1246  20"24" " " 18"22" 0"4" "
*AL1246HD  20"24" " " 18"22" 0"4" "
AL125HD


6"—18" 7.5"—13.5" " 6"16" 7.5"13.5" "
AL1252  18"20" 7.5"—13.5" " 16"18" 7.5"13.5" "
AL1252HD


18"20" 7.5"—13.5" " 16"18" 7.5"13.5" "
*AL1255HD


20"23" 7.5"—13.5" " 18"21" 7.5"13.5" "
*AL1256  20"24" 7.5"—13.5" " 18"22" 7.5"13.5" "
*AL1256HD


20"24" 7.5"—13.5" " 18"22" 7.5"13.5" "
*AL1258HD


24"26" 7.5"—13.5" " 22"24" 7.5"13.5" "
H300102  6"19" " " 6"17" 0"4.5" "
*AL12332  21"30" " " 19"28" 0"4" "
Class 5
AL123V  6"18" " " 6"16" 0"8" "
AL1232V  18"20" " " 16"18" 0"8" "
*AL1235V  20"23" " " 18"21" 0"8" "
*AL1236V  20"24" " " 18"22" 0"8" "

""
