Harmar Mobility AL010 - Motor Cover Wiring Schematic

Outside Vehicle Lis: Installaon & Service Manual
06DEC19 | P/N: 630-00106 REV A
32
OUTSIDE VEHICLE LIFTS: SECTION 8
MOTOR COVER WIRING SCHEMATIC

Motor Cover Wiring Schemac
CIRCUIT
BREAKER
BATTERY
VEHICLE HARNESS
KEY SWITCH
LIFT
LIGHT
TRAILER PLUG
MOTOR COVER
LIGHT
ACTUATOR
POLE REVERSING
SWITCH
12 V +
