Vol. II-2-14 Harris Stratex Networks
Chapter 2. Eclipse Terminals
Figure 2-5.
Connect ES Options with ODU 300hp or ODU 300ep: ETSI
Table 2-7. Connect ES Options with ODU 300hp or ODU 300ep: ETSI
Ethernet
BW, Mbps
Channel
BW, MHz
Modulation License Connect ES Option
10
1
1. A 10 Mbps, 3.5 MHz, 16 QAM option is planned for later release. Contact
Harris Stratex Networks or your supplier for details.
7 QPSK Base Connect ES 50
20 7 16 QAM Base Connect ES 50
20 14 QPSK Base Connect ES 50
32 7 64QAM Base Connect ES 50
40 28 QPSK Base Connect ES 50
40 14 16QAM Base Connect ES 50
55 14 32QAM Base Connect ES 50
64 28 16 QAM Base Connect ES 50
82 28 16 QAM Upgrade 1 Connect ES 100
106 28 32 QAM Upgrade 1 Connect ES 100
150 28 128 QAM Upgrade 2 Connect ES 150
150 56 16 QAM Upgrade 2 Connect ES 150
190 28 256QAM Upgrade 3 Connect ES 200
196 56 64 QAM Upgrade 3 Connect ES 200
