Harris DataSmart 763 - Page 38

38
 4500
 6000
Pressing BACK returns the user to the previous screen without saving changes.
Switchover pressure is changed by pressing to decrease and to increase. Pressure value increases and
decreases in increments of 12. Default pressure is set to 200. Minimum allowable pressure is 70; maximum allowable
pressure is 2400.
Cylinder Capacity and Sensor Readings are required fields. Default Switchover Pressure (200) can be used.
