1 General Information
Monitor Outputs
Output Source Impedance: <3 ohms, balanced
Output Load Impedance: 1 k ohms minimum
Output Level: +4 dBu nominal, +24 dBu maximum
Frequency Response
Line Input to Program or Send Output: +0 dB/-0.5 dB,
20 Hz to 20 kHz
Dynamic Range
Analog Input to Analog Output: 104 dB referenced to
FSD, 107 dB “A” weighted to FSD
Analog Input to Digital Output: 105 dB referenced to
FSD, 108 dB “A” weighted to FSD
Digital Input to Analog Output: 110 dB referenced to
FSD, 113 dB “A” weighted to FSD
Digital Input to Digital Output: 125 dB
Total Harmonic Distortion + Noise
Analog Input to Analog Output: <0.003%, 20 Hz to
20 kHz, +18 dBu input, +18 dBu output
Digital Input to Digital Output:
<0.0005%, 20 Hz to
20 kHz, -6 dB FSD input, -6 dB FSD output
Digital Input to Analog Output:
<0.003%, 20 Hz to
20 kHz (<0.001%, typical at 1 kHz), -6 dB FSD
input, +18 dBu output
Crosstalk Isolation
Program-to-Program or Program-to-Send:
>95 dB, 20
Hz to 20 kHz
Stereo Separation
Analog Program Outputs:
>86 dB, 20 Hz to 20 kHz
Console Power Requirements
RMXd8-HL: 48 watts
RMXd-12: 99 watts
RMXd-20
:
141 watts
RMXd-28
:
186 watts
Measured at 115/230 VAC, ±12%, 50/60 Hz
Power Supply Voltage
Console power: +48 VDC at 6.25 Amps.
(The console includes an integral power cou-
pler for a primary and a redundant supply. One
supply is included with the mainframe, along
with two DC power cables.)
Power Supply Ground
Rack mounted power supply: grounded through AC
cord
Power Supply Connection
AC input: IEC power cord
DC output: Keyed multi-pin connector
Dimensions
For all RMXdigital frames: height above countertop
is 2.25" [57]. Depth below countertop is 9.85"
[250] at the rear of the frame. Front-to-back
depth is 22" [559]. See page 2-1 for a side view
with dimension details.
RMXd-12 is 27.4" [696] wide
RMXd-20 is 40.2" [1021] wide
RMXd-28 is 53.0" [1346] wide
RMXd8-HL (Rack mounted):
2 RU: 3.5" [89] x 19" [483] x 10" [254]
Console Display (sits/stands on countertop):
Original Tall Display: 11.13" [283] x 14.25"
[362] x 5.1" [130]
Low-Profile Display: 5" [127] x 17.25" [438] x
5.25" [133]
48 Volt Power Supply (Rack mounted):
2 RU: 3.5" [89] x 19" [483] x 10" [254]
All dimensions: Height x Width x Depth.
Harris Corporation reserves the right to change
specifications without notice or obligation.
