to 15 sources), and defines the sources for
the seven monitor select buttons.
[monitor_selection]
Include_1=D9.337-351,173,175
definekey_1=10
definekey_2=5
definekey_3=0
definekey_4=1
definekey_5=2
definekey_6=3
definekey_7=4
• [meter_selection] This section has the
include list and the seven button definitions
for the auxiliary meter buttons. The entries
are like those in the [monitor_
selection] section above.
• [studio1_selection] This section has
the include list and the seven button defi-
nitions for the studio monitor buttons. The
entries are like those in the [monitor_
selection] section above.
• [on_out_port_card_x] This section
sets the relationship of the output logic for
each Assignable logic connector on the KSU
(card_4) and the three possible 8-Input
Expansion cards (card_1, card_2,
card_3) and the timeslots the logic sig-
nals will use.
There can be up to sixteen line entries:
on_out_port_a=b,c that define the two
logic outputs (called ports) on pin 5 and
pin 11 of each Assignable Logic connector.
a is the port number. It will be 1 to 6 on
the KSU (to define the outputs on the B, C
and D connectors) and from 1 to 16 on each
8-Input Expansion card (to define the two
outputs on each logic connector).
b defines the logic action. It can be 121
(for an On Tally output), 122 (for an Off
Tally output), 123 (for a start pulse) or 124
(for stop pulse).
c defines which timeslots are used by
the logic commands. Typically the odd num-
bered timeslots, starting with slot 1, are used
in order. This gets automatically assigned
by the VMCC as the ports are defined.
• [port_config_card_x] This section
defines logic outputs (those not defined in
the [on_out_port_card_x] section) for
use as directly addressed outputs. One of
four logic commands can be assigned to
each output, but only two: 1, which defines
the output as closed or 2, which defines it
as an open command, are very useful.
There could be up to sixteen line entries
(for an 8-Input Expansion card) under this
heading. The entries port_config_h=i
define each port.
h is the port number (from 1 to 16) which
is set for one of the four types of logic func-
tions.
i is the logic function: 0 is a pulsed close
command, 1 is a sustained close, 2 is a sus-
tained open, and 3 is a pulsed open com-
mand.
• [on_out_ts_card_x] This section sets
the binding of the logic inputs on the As-
signable logic connectors on the KSU
(card_4) and the three possible 8-Input
Expansion cards (card_1, card_2,
card_3). There can be up to sixteen line
entries under this heading. The entries:
on_out_ts_d_i=e,f,g define each port.
d
is the port number (from 1 to 16), and
i is a sequential entry number starting with
1. The port used as the input is set by e
(from 1 to 32). The logic function is defined
by f (a logic binding bit between 1 and 255)
and it is assigned to the input timeslot g
(from 1 to 16).
Refer to Appendix A for additional command
entry information for session and macro files.
