while channel 2 is immediately turned Off—even
if the channel is on-air.
Typically, there are no entries under the [On]
heading unless the console is being setup for non-
attended operation (e.g. slaved to a digital deliv-
ery system).
[TelcoRecord] and [TelcoMonitor]
Each Telco channel can be assigned to the Telco
Monitor bus and/or to the Telco Record bus un-
der these two sections. To assign the Telco chan-
nel, the default setting (=0) is changed to =1. This
sets that Telco channel as active on that bus as in:
[TelcoRecord]
Channel_81=1
Channel_82=0
Channel_83=0
Channel_84=0
This sets Telco channel 1 (ID # 81) as feeding
the Telco Record output, while the other Telco
channels do not feed the Telco Record output.
SESSION FILE SECTION SUMMARY
Within each of these sections, each channel but-
ton can be set either On (=1) or Off (=0) when the
session file loads:
• [Cue] Sets whether cue is on or off for
each channel.
• [Send_1] Sets whether the channel is as-
signed to the send bus.
• [Prog_1, Prog_2, Prog_3, Prog_4]
Sets whether the channel is assigned to any
of the Program buses.
• [Offline_1] Sets whether the channel
is assigned to the Offline bus.
• [Send_1_PF] Sets whether the channel’s
send feed is pre-fader or post-fader (default).
• [Send_1_PS] Sets whether the channel’s
send is pre-switch or post-switch (default).
• [PanBalance] Sets whether the channel’s
pan/balance control is on or off.
• [TelcoAuto] Sets whether the Auto
Foldback feature is on or off for each Telco
channel.
• [TelcoRecord] Sets whether the Telco
channel feeds the Telco Record bus.
• [TelcoMonitor] Sets whether the Telco
channel feeds the Telco Monitor bus.
• [Mode] Sets the channel’s default mode.
This section has four values: Stereo (=0),
Left only (=1), Right only (=2), or Mono
Sum (=3).
• [local_cough] Sets whether the On but-
ton functions as a cough button when the
channel source is a mic and it is On. Press-
ing and holding the On button removes the
mic’s audio from all assigned buses.
• [timer_reset] Sets the channel to re-
set the event timer, when the timer’s Auto
button is lit, when the channel is turned
On. If Auto is not lit, or if the entry is =0,
then there is no timer reset at channel on.
• [fader_start] Sets the channel to au-
tomatically turn on when the fader is moved
up from full off and to turn off when moved
back to full off. =0 means fader movement
does not affect on/off status.
• [port_event_card_x] Commands a
logic output for any Assignable logic con-
nector on the KSU (card_4) and the three
possible 8-Input Expansion cards (card_1,
card_2, card_3).
There could be up to sixteen line entries
under the heading: port_event_j=k to
define each port. j is the port number (from
1 to 16) with the event function k (0 is a
null event and 1 is a trigger).
CHANNEL LOCKOUT SECTION
This section sets whether any channel buttons
are locked out, preventing changes to the session
file settings by the board operator. Channel lock-
