HART HTMS01 - Page 19

19 – English
VIEW OF BLADE NOT SQUARE WITH FENCE,
ADJUSTMENTS ARE REQUIRED
SOCKET HEAD
SCREW(S)
SOCKET HEAD
SCREW(S)
MITER
FENCE
INDICATOR
SCREW
SCALE
INDICATOR
MITER
SCALE
MITER
FENCE
MITER
TABLE
BLADE
SQUARE
SCALE
INDICATOR
INDICATOR
SCREW
BEVEL
SCALE
 Loosenthefencescrewandslidethepartialslidingmiter
fencetowardthebladetoaccessthesocketheadscrews
securingtheleftmiterfencetothetable.
 Usingthebladewrench,loosenthesocketheadscrews
thatsecurethemiterfencetothemitertable.
 Rotatethemiterfenceleftorrightuntilthesawbladeis
parallelwiththesquare.
SLIDING
PARTIAL FENCE
FENCE
SCREW
ASSEMBLY
FIG. 18 FIG. 20
FIG. 19
FIG. 21
 Retightenthescrewssecurelyandrechecktheblade-to-
fencealignment.
Yoursawhasseveralscaleindicators.Aftersquaringadjust-
mentshavebeenmade,itmaybenecessarytoloosenthe
indicatorscrewsandresetthemtozero.See figures 20 - 21.
BEVEL
LOCK KNOB
