Blood pressure monitor
1 Extra large LCD display with illumination
2 START/STOP button
3 Memory key for User 1
4 Memory key for User 2
5 Cuff connector socket
6 Battery compartment
7 USB port
8 Mains socket
Cuff
9 Secure fit cuff (a) with application instructions (b)
10 Grip tab to pull on the cuff
11 Size scale for correct adjustment of the cuff
12 Cuff plug
13 Extra long cuff tube
14 Lower arm opening for correct and secure fit
Display
15 Systolic blood pressure
16 Diastolic blood pressure
17 Pulse rate
18 Flashes when the device is measuring and the pulse rate is detected
19 Irregular heartbeat
20 Oscillometric measurement
21 Korotkoff measurement
22 Trac light system for your values / progress bar
23 ‘Measurement OK’ / cuff fit check / rest indicator symbols
24 Temperature symbol
25 User memory
26 Battery symbol
27 Average value (A), morning (AM), evening (PM) / memory allocation number
28 Date and time display
