Youwillndthatholdingthecamerainyourlefthand
and the lens in your right hand, as shown in the illus-
tration, is the easiest way of attaching the lens.
When you have aligned the red index on the lens with
the one on the camera as shown in the illustration, the
lenswill dropeasily intothe bayonettting.Youcan
then rotate it clockwise until it stops with a faint click
as the lens catch locks it in place.
Removing the Lens
Depress the lens release button and rotate the lens
counter-clockwise until it stops.
NOTE: You can only remove the lens when the cam-
era is cocked (fully wound) and not in the pre-re-
leased mode (see page 13).

Hasselblad 503CX Specifications

General

Camera Type	Medium format SLR
Image Size	6x6 cm
Focus	Manual
Film Format	120/220
Lens Mount	Hasselblad V-system
Shutter Speed	1/500 sec to 1 sec, Bulb
Viewfinder	Interchangeable waist-level or prism
Shutter Type	Focal-plane shutter
