Hatz 2-4L30 - Balancing Weights; Bearing Point Diameters - Two- and Three-Cylinder Engines; Bearing Point Diameters - Four Cylinder Engines

Repair data
4
L / M . . / 07.96
Balancing weights
Bearing point diameters – two- and three-cylinder engines
Balancing weight shaft mm 28 h 5
0
-0.009
Axial clearance – two-cylinder engines mm 0.15 - 0.6
– three-cyliner engines mm 0.15 - 0.7
Wear in the needle roller ∅ mm bis 27.97
bearing area
Bearing point diameters - four cylinder engines
Bearing journals for balancing weights mm 44 d 6
-0.080
-0.096
Bearing bushing for balancing mm 44
+0.018
weights (pressed-in)
+0.083
Endplay mm 0.15 - 0.4
