Operation and use 2L41C, 2M41, 2M41Z
48
HATZ
Operator’s Manual
CAUTION
Danger of injury
Prolonged contact with engine oil can lead to irritation of the
skin.
▪ Wear safety gloves.
▪ If there is contact with the skin, thoroughly wash the af-
fected areas of the skin with soap and water.
CAUTION
Danger of later engine damage.
▪ Operating the engine with an oil level below the min. mark
or above the max. mark can lead to engine damage.
▪ When checking the oil level, the engine must be horizontal
and have been switched off for a few minutes.
Overview — Checking oil level/adding oil
Pos. Designation
1 Dipstick
2 Code letter on the dipstick
Procedure — Checking oil level/adding oil
Step Activity
1 Switch off the engine and wait several minutes for the engine oil
to collect in the crankcase. Engine must be level.
2 Remove contamination on the engine in the area of the dipstick
(1).
3 Pull out the dipstick and clean it.
