4.3. Stopping the engine
If operation of the engine is interrupted
for any reason, or at the end of the
working day, the starter key should be
kept out of reach of unauthorised per-
sons.
Stop via engine speed setting lever
20
– Move the speed adjustment lever back
to the STOP position. The engine cuts out.
Stop via the stop lever (optional equipment)
21
– Press the stop lever down towards STOP and
hold it until the engine has come to a stand-
still.
When the engine is not running any longer,
release stop lever. The stop lever is returned
automatically to its operating position START
via a spring (Fig. 21).
22
The charge 2 and oil pressure pilot lamps 3
come on.
– Turn the starter key to the 0 position and pull
it out. The pilot lamp lights must then go out.
23
Engines equipped with stop solenoid can also
be stopped by turning the starter key back to
position 0.
