3. General notes
3.1. Technical data
1)
These values are intended as an approximate guide. The max. marking on the dipstick is the
determining factor.
2)
Exceeding these limits causes engine breakdown.
Type 2W35 3W35 4W35 4W35T
Design Fluid-cooled four-stroke diesel engine
Combustion air normal intake
turbo-
charged
Combustion system Direct injection
Number of cylinders 2 3 4 4
Bore / stroke mm 70/90 70/90 70/90 70/90
Displacement
cm
3
692 1038 1384 1384
Lubricating oil capacity l. approx.
2.5
1)
3.4
1)
4.4
1)
4.4
1)
Difference between
“max” and “min” levels
l. approx. 1.2
1)
1.4
1)
1.6
1)
1.6
1)
Lubricating oil consumption
(after running in)
approx. 0.5 % of fuel consumption at full load
Lubricating oil pressure
(oil temperature 100 °C)
approx. 3.5 bars at 3000 r.p.m.
Capacity of coolant
with HATZ standard radiator
l. approx. 4.6 5.4 6.7 6.7
Direction of rotation,
looking at the flywheel
counterclockwise
Max. admissible tilt angle in operation
(with lub-oil level at max. marking of dip-
stick with the engine in horizontal position)
max. 30° in any direction
2)
Weight (incl. electric starter, air-cleaner
and exhaust silencer) without radiator
kg approx. 74 89 107 111
Battery capacity 12V / 55 Ah
