104 24203 3237 0 E 06 10 EN
F
- Special procedure
Engine-powered articulated lifts, 12 - 26 m
This pump can be used in combination with a manual electro-distributor control, to perform the
movement required to lower the platform :
• Arm lowering.
• Boom lowering.
• Telescope retraction
• Turntable rotation.
• Jib lowering.
• The operator must fasten himself by using 2 straps. One strap is attached to the platform, the other
to the structure.
• The operator must exit the platform via the standard access point.
• The operator must not detach the strap connected to the platform until transfer is complete or while it
still presents a danger.
1. Insert the lever ( 1 ) in the socket of the pump.
2. Check that the pump decompression valve ( 2 ) is in
closed position.
3. Push the lever from top to bottom several times whilst
keeping the manual electro-distributor control for the
requirement movement shown on the plate pressed 3.
If the operator in the platform must exit the platform to go on a sturdy, safe structure, the transfer must
respect the following recommendations :
If the operator cannot be lowered by any of the above mentioned methods, contact HAULOTTE Services®
immediately.
1
2
3
