Haulotte HT23RTJ O User Manual

511 4001055250 E 10.21 USA / GB
HT23RTJ O - HT23RTJ O SW - HT67RTJ O - HT23RTJ PRO - HT23RTJ PRO SW - HT67RTJ PRO
E - Trouble shooting and diagram
Marking Description
FU1 Fuse -10 A - Engine shutdown
FU2 Fuse - 20A - Starter
FU3 Not used
FU4 Fuse - 25A - Generator
FU5 Fuse - 30A - General
FU6 Not used
FU7 Fuse - 15A - ECU
FU8 Fuse - 20A - Option
FU9 Fuse - 20A - Attachments
FU10 Not used
FU11 Fuse - 7.5A - + Permanent
FU12 Not used
FU13 Fuse - 20A - Power
FU14 Not used
FU15 Not used
FU16 Not used
FU17 Not used
FU18 Not used
FU19 Fuse - 5A - Emergency stop and selectors
KA1 Relay - 1RT - 12V - Engine shutdown
KA2 Relay - 1RT - 12V
KA3 Solenoid valve
KA4 General
KA5 Relay - 1RT - 12V - Engine speed
KA9 Relay - 1RT - 12V - Horn
KMG Relay - 1T - 12V/70A - Main relay
KMP Relay - 1T - 12V/70A - Power
