174 4001055250 E 10.21 USA / GB
Upper boom
Procedure of dismantling / reassembling cage
MS0027
1. Control box cover
2. ASB2
3. Upper control box
4. Link part : Platform
5. Vibrating cords
6. Platform support
7. Flooring
8. Platform
9. Tool tray
