PARTS LIST AND SCHEMATIC DRAWING
PART
N
O.
DESCRIPTION QTY.
1 Height adjustment
knob
4
2 Work support
mounting bracket
2
3 Length knob 2
4 Work support 2
5 Extension rail 2
6 Saw mounting
bracket
1pair
7 Nut M8 4
8 Lock washer
(diameter 8)
4
9 Flat washer
(diameter 8)
4
10 Mitre saw stand 2
11 Carriage bolt 2
