Appendix C
Specifications
Wireless-G Router
Model HWR54G Rev. R
Dimensions 141mm(W) * 100mm(D) * 27mm(H)
Operating Tempera-
ture
-10° C to 55° C
Storage Temperature -20° C to 70° C
Network Protocol: TCP/IP
Network Interface: 5 Ethernet:
4 * 10/100BaseT (RJ45) LAN connection
1 * 10/100BaseT (RJ45) for WAN
LEDs 12
Power Adapter 12 V DC / 0.8A External
Wireless Interface
Standards IEEE802.11g WLAN, JEIDA 4.2, roaming support
Frequency 2.4 to 2.4835GHz (Industrial Scientific Medical Band )
Channels Maximum 14 Channels, depending on regulatory authorities
Modulation DSSS BPSK/QPSK/CCK, OFDM/CCK
Data Rate Up to 54 Mbps
Coverage Area Indoors : 15m @54Mbps, 120m @6Mbps or lower
Outdoors : 40m @54Mbps, 300m @6Mbps or lower
Security 64Bit, 128Bit WEP, WPA, WPA2, WPA-Radius, WPA2-Radius
TKIP, AES
Output Power 13dBm (typical)
Receiver Sensitivity -80dBm Min.
C
