Converting the line trimmer for edging
1) Pull back the locking (8).
2) Rotate the upper handle (2) 90°.
3) Release the locking collar (8), it will return automatically and lock the upper handle (2).
4) The cutting head is now turned 90° for edging.
Setting the position and angle of the auxiliary handle
1) Loosen the locking knob (5).
2) Disengage the handle from the clamp and move the handle (6) up and down until the required
position is reached.
3) Re-tighten the locking knob (5).
5
6
7
