Hayter R53A Parts Catalog

111-2845 Rev A
Side Discharge Chute Assembly
3
Rear Wheel, Transmission and
Ref Part No. Qty. Description
Bolt-Shoulder1
614650
2
Rear Wheel ASM2
117-4104
2
Ring-Retaining3
32151-61
2
Pinion4
110-9417
2
Washer-Plain5
36-4780
2
Screw-Plastite6
108-7476
3
Cover-Wheel, ASM7
117-4197
2
Washer-Stepped7:2
614426
1
Ring-Retaining8
32151-36
2
Arm-Rear Pivot, LH9
108-9344
1
Arm-Spring, Rear10
110-9445
2
Knob-HOC11
110-7125
2
Retainer-Bearing12
110-9422
2
Bearing-Ball13
104-8699
2
V-Belt14
110-9429
1
Shield-Trailing15
112-8768
1
Transmission ASM16
114-2812
1
Chute-Discharge, Side17
105-3028
1
Arm-Rear Pivot, RH18
108-9343
1
Bracket-Transmission19
114-7977-03
1
Screw-HWH20
99-8445
2
Spring-Torsion21
99-5293
1
Bracket-Cover22
112-6416
1
Rod-Cover23
99-5291
1
Ref Part No. Qty. Description
Discharge Door ASM24
106-8376
1
Latch-Door24:2
107-0795
1
Cap-Door24:3
107-7456
1
Screw-Plastite24:4
107-7461
1
Ring-Clip, Locking25
65-2720
1
Cover-Shaft, Drive28
24-7922
1
Cap-Bearing29
114-2755
2
4

Hayter R53A Specifications

General

Brand	Hayter
Model	R53A
Category	Lawn Mower
Language	English
